REED SD-6100 Data Logging Force Gauge, 220lbs (100kg)

Measuring Range 100kg
220.5lb
980.6N
Accuracy ±(0.5% rdg + 2 dgt.)
Resolution 0.15 kg/0.02 lb/0.02 N
Response Time Less than 1 sec.
Full Scale Deflection Less than 1mm
Display 4-digit LCD
Backlit Display Yes
Peak Hold Measurements Yes
Zero Adjustment Yes
Overrange Indicator Yes (Audible alarm at 100kg)
Datalogging Capabilities Yes
Real-Time Clock and Date Stamp Yes
Selectable Sampling Rate Yes (1, 2, 5, 10, 30, 60, 120, 300, 600, 1800, 3600s)
External Memory Yes, expandable up to 16Gb with SD card (optional)
Auto Shut-off Yes (after 10 mins/off)
Low Battery Indicator Yes
Power Supply 6 AA Batteries or AC Adapter (optional)
Output Yes
Battery Life Sampling Time Dependent
PC Connectivity USB Cable (optional)
Software SW-U801-WIN Software (optional)
Software OS Compatibility Windows XP / Vista / 7
Product Certifications CE
Operating Temperature 0 to 122°F (0 to 50°C)
Storage Temperature 14 to 140°F (-10 to 60°C)
Operating Humidity Range 10 to 85%
Dimensions 215 x 90 x 45mm (8.5 x 3.5 x 1.8″)
Weight 1.43 lb (650 g)
Category:

Description

REED SD-6100 Offers

This gauge has the ability to measure push and pull forces up to 220lbs (100kg) and features a reversible display ensuring measurements are easily read, regardless of testing direction. The SD-6100 features a real time datalogger with memory card slot. Using a SD card (max 16Gb), a user can select a desired sampling rate and quickly generate an Excel file on a SD card without the use of software. Optional accessories include an AC adapter for continuous long-term monitoring and PC software to track real-time measurements.

Features

  • Measures tension and compression
  • Records in Peak hold or Normal mode
  • Fast/Slow response selection
  • Full capacity tare (zero) capability
  • Force is measured in kg, lb or Newtons
  • Easy-to-read backlit display
  • Reversible display ensures legible readings regardless of direction
  • Real-time datalogger with integral SD memory card
  • User selectable sampling rate from 1 to 3600 seconds
  • Optional PC software features live tracking via USB connection
  • Low battery indicator and auto shut off
